【产品特性】
1、采用 SONY CCD传感器,更好的使用寿命、更好的可靠性和稳定性
2、DSP数字信号处理技术,使图像更清晰,轮廓更分明,对比度更强。
3、极好的消除了信号中的干扰超声波、具有高质量的图像和很高的灵敏度
4、利用3D数字降躁系统、能得到更清晰的彩色图像
5、自动增益控制:先进的数字背光补偿功能
6、结构紧凑,外型小巧、功耗低,可以提供相机模组,尺寸: 38*38(MM)
图像清晰、色彩真实、层次感强、是工业仪器用工业相机的最佳选择
【应用领域】
型 号 MODEL | MK-788(彩色) | ||
成像元件 Image Sensor Device | 1/3"SONY CCD | ||
像素 Effective Pixels | 976(H)X582(V) | ||
信号系统 System of Signal | PAL | ||
水平解析度 Horizontal Resolution | 800线 | ||
最低照度 Minimum illumination | 0.1lux at F1.2 | ||
信噪比 S/N Ratio | More than 52dB | ||
自动白平衡跟踪 Auto White Balance | 开/关(Switchable) | ||
自动增益控制 Automatic Gain Control | 开/关(Switchable) | ||
电子快门控制 Electronics Shutter Control | 开/关(Switchable)1/50-1/100,000/sec | ||
背光补偿 Backlight Compensation | 开/关(Switchable) | ||
镜头接口 Lens mounting | C# | ||
视频输出 Video output | 1.0Vp-p,75Ω | ||
供电电源 Power Supply | DC12V | ||
工作温度 Operating Temperature | -10℃-+50℃ | ||
尺寸 Dimension(mm) | 43(W)×63(H)×43(D) | ||
重量 Weight(g) | About 103g |
